Growatt Solar Inverter 5kW 48V SPF5000

R10,800.00 (incl. VAT)


If this product is purchased and no stock is available, our team will contact you with the option of a full refund or suggest an available alternative. Should you wish to confirm stock availability before purchase, please email onlineorders@voltex.co.za

PLEASE NOTE: All Warrantees will be null and void should this unit not have been installed by a qualified electrician with a Certificate of Compliance attached. A walk in warrantee is offered which is subject to our suppliers service procedures.

STEP 2:
SKU: T0004375 Categories: , , Tag:

Description

Growatt Solar Inverter 5kW 48V SPF5000

A multi-function off-grid solar inverter, integrated with a MPPT solar charge controller, a high frequency pure sine wave inverter and a UPS function module, all in one machine. This inverter is ideal for off grid, backup power, and self-consumption applications and can function with or without batteries.

The Growatt Solar Inverter 5kW 48V SPF5000 SPF5000 Solar inverter for backup and self-consumption applications. It has a high voltage PV Input for maximum efficiency and reduced installation cost.

  • Integrated MPPT charge controller.
  • Equalization charging function.
  • Work with or without battery.
  • Maximum PV input voltage up to 450VDC.
  • Configurable grid or solar input priority.
  • Optional WIF/GPRS remote monitoring
  • Support parallel operation for capacity expansion up to 30kW.
  • PV and grid power the load jointly if PV energy is unsufficient.
  • Flexibly schedule the Inverter charging and discharging time
  • Battery Voltage: 48VDC
  • Parallel Capability: Yes, 6 units maximum
  • Efficiency (Peak): 93%
  • Waveform: Pure Sine Wave
  • Transfer Time: 10ms typical, 20ms Max
  • Protection Degree: IP20
  • Net Weight: 12kgs
  • Battery Type: Lithium/Lead Acid
  • Surge Power: 10000VA

Solar Charger:

  • Maximum PV Array Power: 6000W.
  • MPPT Range @ Operating Voltage: 120VDC – 430VDC.
  • Maximum PV Array Open Circuit Voltage: 450vDC.
  • Maximum Solar Charge Current: 100 A.

Visit for more loadshedding solutions

What’s in the box
1 x SPF5000 Inverter
1 x User Manual

View our Solar range HERE

Additional information

Weight 12 kg
Dimensions 33 × 49 × 14 cm
