Schneider Easy9 Circuit Breaker 1 Pole 40A EZ9F53140

R52.00 (incl. VAT)


If this product is purchased and no stock is available, our team will contact you with the option of a full refund or suggest an available alternative. Should you wish to confirm stock availability before purchase, please email onlineorders@voltex.co.za

Description

Schneider Easy9 Circuit Breaker 1 Pole C-Curve Din 40A 3kA 230V EZ9F53140

  • This Easy9 product is a low voltage miniature circuit breaker (MCB).
  • It is a 1P circuit breaker with 1 protected pole and 40A In rated current and C tripping curve.
  • The Icu rated short circuit breaking capacity is up to 3kA at 230VAC conforming to EN/IEC 60898-1 standard.
  • It is compliant with IEC 60898-1 standard.
  • This product has a protection against short circuit and a protection of cable against overloads.
  • It has a fault tripping indication on the front panel by the position of the handle (O-I engraved).
  • This product is dedicated for residential and small commercial buildings.
  • It has an electrical endurance going up to 4000 cycles and a mechanical endurance going up to 10000 cycles.
  • The Ue operational voltage is 230VAC.
  • The Ui rated insulation voltage is 500VAC.
  • The Uimp rated impulse withstand voltage is 4kV.
  • The operating frequency is 50Hz or 60Hz.
  • It can be mounted on DIN rail for modular installation.
  • Its width is 2 pitches of 9mm.
  • The product colour is light grey (RAL7035).
  • The dimensions are (W) 18mm x (H) 81mm x (D) 66.5mm.
  • The weight is 0.105kg.
  • According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure.
  • The operating temperature is -5°C to 60°C.
  • The storage temperature is -40°C to 85°C.

View our Range HERE

Additional information

Weight 1 kg
Dimensions 9 × 1.8 × 8 cm
Brand

Amperage
